10. Gewa-Bohm waldzither in C (311)  £150

Larger photos are available on request.



Late Gewa/Bohm Waldzither – normal tuners

    This is an old domeback  Waldzither, made in Germany , mid 20th century by Gewa under the Bohm label, after they had taken over the firm, so it dates from after 1936  and before 1960ish. They continued to make Bohm style instruments, with Preston and normal heads.

   It has the original rosewood finger-board and brass frets. The spruce top is in good condition, with ONE repair. The 2-piece ‘flat’ back is sound. The tuners are original, and in good condition, but the tail-piece and rosewood and bone bridge are new. The instrument top only is refinished in Tru-oil. It has been strung as a waldzither in C with Optima waldzither, silver-wound, strings, and is now playing well with a full, ringing, sonorous sound and an easy action.

    Other than cleaning, I have carried out the following work on this instrument: 1) repaired 1 shrinkage splits in the top; 2) revarnished the top; 3)shimmed the original fingerboard for a better bridge height; 4) removed slight warpoing around soundhole and re-enforced beneath; 5)made and fitted new bridge in rosewood and bone; and 6) fitted new tail piece and strap button.



Waldzither Specifications (In Millimetres)

Overall Length of waldzither

790mm

Width at widest point

320mm

Approx. Depth of waldzither

100mm at bridge.

Finish

Top refinished in Tru-oil, a hard, very thin, modern oil-varnish that allows maximum vibration in the wood. Otherwise all original finish, lightly scuffed in places.

Belly wood

Fair quality, book-matched spruce, with purfling and edging all in good condition.

Sound hole

Round, approx. 85mm. diameter.  Purfling and rosewood edging.

Scratchplate

N/A

Back

2 piece dome back in stained maple.

Neck and Head

Two-piece, stained, neck and head.

Sides

Stained maple, good condition.

Fingerboard

 Original in rosewood, now set on a shim. 18 original brass fret, newly levelled. Brass zero fret. MOP position markers at frets 3, 5, 7, 9 and 12. Original rosewood nut.

Machine heads

Original brass and steel tuners, all working well.

Tailpiece

New in steel with 8 string hooks and a strap hook, but I have also fitted a strap post.

Bridge

New in rosewood and bone

Scale Length Bridge to nut

Scale of 466mm

G string height at bridge

17.5mm

E string height at bridge

18mm

12th fret to bottom string (Action)

2mm

12th fret to top string (Action)

1.75mm

Width of fretboard at nut

40mm

Width of fretboard at widest point

52mm
